WANG Feng-yi, WANG Pu, WANG Yu, et al. Randomized Controlled Trial of the Effects of Repetitive Transcranial Magnetic Stimulation and Mirror Therapy on Phantom Limb Pain in Amputees[J]. Journal of Sichuan University (Medical Sciences), 2022, 53(3): 474-480. DOI: 10.12182/20220560209
Citation: WANG Feng-yi, WANG Pu, WANG Yu, et al. Randomized Controlled Trial of the Effects of Repetitive Transcranial Magnetic Stimulation and Mirror Therapy on Phantom Limb Pain in Amputees[J]. Journal of Sichuan University (Medical Sciences), 2022, 53(3): 474-480. DOI: 10.12182/20220560209

Randomized Controlled Trial of the Effects of Repetitive Transcranial Magnetic Stimulation and Mirror Therapy on Phantom Limb Pain in Amputees

More Information
  • Corresponding author:

    YANG Yong-hong, E-mail: nicole308@126.com

  • Received Date: June 07, 2021
  • Revised Date: February 14, 2022
  • Available Online: May 24, 2022
  • Published Date: May 19, 2022
  •   Objective  To investigate the effect of repetitive transcranial magnetic stimulation (rTMS) on phantom limb pain (PLP) in amputees, and to compare the therapeutic effect with that of mirror therapy (MT).
      Methods  The study was designed as a randomized controlled trial. The evaluators were blinded, while the subjects and the therapists were unblinded. Subjects were randomly assigned to either the rTMS group or the MT group with a computer-generated random number table. From June 2018 to December 2020, from out of 45 amputee patients screened for the study, 30 who met the inclusion criteria were recruited for the study. All patients were recruited from the Rehabilitation Medicine Center, West China Hospital, Sichuan University. In the end, 4 patients withdrew from the study and 26 patients (12 in the rTMS group and 14 in the MT group) completed the prescribed treatment and evaluation. The rTMS group was given rTMS (1 Hz, 15 min, 5 d/week) for 2 weeks in addition to conventional rehabilitation therapy, while the MT group received MT (corresponding movements of limbs, 15 min, 5 d/week) for 2 weeks in addition to conventional rehabilitation therapy. PLP was evaluated by the Visual Analogue Scale (VAS) and Douleur Neuropathique 4 Questions (DN-4). Subjects were assessed before treatment (t0), immediately after the completion of the treatment (t1) and 3 months after the completion of the treatment (t2).
      Results  The mean age of the 26 patients was 39.73±12.64. There were 15 males and 11 females. According to the reported description of the characteristics of the PLP by the patients, the characteristics with the highest incidence were tingling, stabbing, numbing, electric shocks and burning in descending order. There was no significant difference in the incidence of PLP characteristics between the two groups (P>0.05). The two groups had comparable baseline data, showing no significant difference in VAS and DN-4 between the two groups at t0 (P>0.05). At t1 and t2, the VAS and DN-4 scores were decreased from those of t0, showing statistically significant difference in both groups (P<0.01 for both scores). In the rTMS group, there was no significant difference between VAS and DN-4 scores at t1 and those at t2 (P>0.05). In the MT group, the VAS and DN-4 scores at t2 were significantly lower than those of t1 (P<0.05). There was no statistically significant difference between the rTMS group and MT group in the changes in pain measurements, i.e., VAS and DN-4 scores, before and after the intervention (P>0.05). The 26 patients who completed the experiment showed no dizziness, headache, or other abnormalities during the study.
      Conclusion  The results of this study indicate that repetitive transcranial magnetic stimulation could improve PLP in amputees, and the improvement effect was comparable to that of mirror therapy.
  • [1]
    ORTIZ-CATALAN M, GUDMUNDSDOTTIR R A, KRISTOFFERSEN M B, et al. Phantom motor execution facilitated by machine learning and augmented reality as treatment for phantom limb pain: A single group, clinical trial in patients with chronic intractable phantom limb pain. Lancet,2016,388(10062): 2885–2894. DOI: 10.1016/S0140-6736(16)31598-7
    [2]
    YILDIRIM M, KANAN N. The effect of mirror therapy on the management of phantom limb pain. Agri,2016,28(3): 127–134. DOI: 10.5505/agri.2016.48343
    [3]
    WEEKS S R, ANDERSON-BARNES V C, TSAO J W. Phantom limb pain: Theories and therapies. Neurologist,2010,16(5): 277–286. DOI: 10.1097/NRL.0b013e3181edf128
    [4]
    KERN U, BUSCH V, ROCKLAND M, et al. PrevSalence and risk factors of phantom limb pain and phantom limb sensations in Germany. A nationwide field survey. Schmerz,2009,23(5): 479–488. DOI: 10.1007/s00482-009-0786-5
    [5]
    BALAKHANLOU E, WEBSTER J, BORGIA M, et al. Frequency and severity of phantom limb pain in veterans with major upper limb amputation: Results of a national survey. PM R,2021,13(8): 827–835. DOI: 10.1002/pmrj.12485
    [6]
    EPHRAIM P L, WEGENER S T, MACKENZIE E J, et al. Phantom pain, residual limb pain, and back pain in amputees: Results of a national survey. Arch Phys Med Rehabil,2005,86(10): 1910–1919. DOI: 10.1016/j.apmr.2005.03.031
    [7]
    EICHENBERGER U, NEFF F, SVETICIC G, et al. Chronic phantom limb pain: The effects of calcitonin, ketamine, and their combination on pain and sensory thresholds. Anesth Analg,2008,106(4): 1265–1273. DOI: 10.1213/ane.0b013e3181685014
    [8]
    AHMED A, BHATNAGAR S, MISHRA S, et al. Prevalence of phantom limb pain, stump pain, and phantom limb sensation among the amputated cancer patients in India: A prospective, observational study. Indian J Palliat Care,2017,23(1): 24–35. DOI: 10.4103/0973-1075.197944
    [9]
    ICHINOSE A, SANO Y, OSUMI M, et al. Somatosensory feedback to the cheek during virtual visual feedback therapy enhances pain alleviation for phantom arms. Neurorehabil Neural Repair,2017,31(8): 717–725. DOI: 10.1177/1545968317718268
    [10]
    BARBIN J, SEETHA V, CASILLAS J M, et al. The effects of mirror therapy on pain and motor control of phantom limb in amputees: A systematic review. Ann Phys Rehabil Med,2016,59(4): 270–275. DOI: 10.1016/j.rehab.2016.04.001
    [11]
    KIKKERT S, MEZUE M, O'SHEA J, et al. Neural basis of induced phantom limb pain relief. Ann Neurol,2019,85(1): 59–73. DOI: 10.1002/ana.25371
    [12]
    王凤怡, 张嘉祺, 张梦杰, 等. 镜像疗法改善截肢患者幻肢感及幻肢痛疗效的系统评价. 中国循证医学杂志,2016,16(2): 160–165.
    [13]
    张仁刚, 刘沙鑫, 王凤怡, 等. 重复性经颅磁刺激联合感知提醒对脑卒中患者单侧忽略的影响研究. 四川大学学报(医学版),2017,48(2): 309–313.
    [14]
    LEE J H, BYUN J H, CHOE Y R, et al. Successful treatment of phantom limb pain by 1 Hz repetitive transcranial magnetic stimulation over affected supplementary motor complex: A case report. Ann Rehabil Med,2015,39(4): 630–633. DOI: 10.5535/arm.2015.39.4.630
    [15]
    MALAVERA A, SILVA F A, FREGNI F, et al. Repetitive transcranial magnetic stimulation for phantom limb pain in landmine victims: A double-blinded, randomized, sham-controlled trial. J Pain,2016,17(8): 911–918. DOI: 10.1016/j.jpain.2016.05.003
    [16]
    AHMED M, MOHAMEDA S A S D. Long-term antalgic effects of repetitive transcranial magnetic stimulation of motor cortex and serum beta-endorphin in patients with phantom pain. Neurol Res, 2013,2011,33(9): 953–958. DOI: 10.1179/1743132811Y.0000000045
    [17]
    万丽, 赵晴, 陈军, 等. 疼痛评估量表应用的中国专家共识(2020版). 中华疼痛学杂志,2020,16(3): 177–187. DOI: 10.3760/cma.j.cn101379-20190915-00075
    [18]
    李君, 冯艺, 韩济生, 等. 三个中文版神经病理性疼痛诊断量表的制定与多中心验证. 中国疼痛医学杂志,2011,17(9): 549–553. DOI: 10.3969/j.issn.1006-9852.2011.09.011
    [19]
    FLORENCE S L, KAAS J H. Large-scale reorganization at multiple levels of the somatosensory pathway follows therapeutic amputation of the hand in monkeys. J Neurosci,1995,15(12): 8083–8095. DOI: 10.1523/JNEUROSCI.15-12-08083.1995
    [20]
    FLOR H, NIKOLAJSEN L, STAEHELIN JENSEN T. Phantom limb pain: A case of maladaptive CNS plasticity? Nat Rev Neurosci,2006,7(11): 873–881. DOI: 10.1038/nrn1991
    [21]
    PACHECO-BARRIOS K, PINTO C B, SALEH VELEZ F G, et al. Structural and functional motor cortex asymmetry in unilateral lower limb amputation with phantom limb pain. Clin Neurophysiol,2020,131(10): 2375–2382. DOI: 10.1016/j.clinph.2020.06.024
    [22]
    DIERS M, KAMPING S, KIRSCH P, et al. Illusion-related brain activations: A new virtual reality mirror box system for use during functional magnetic resonance imaging. Brain Res,2015,1594: 173–182. DOI: 10.1016/j.brainres.2014.11.001
    [23]
    BLEAKMAN D, ALT A, NISENBAUM E S. Glutamate receptors and pain. Semin Cell Dev Biol,2006,17(5): 592–604. DOI: 10.1016/j.semcdb.2006.10.008
    [24]
    NURMIKKO T, MACIVER K, BRESNAHAN R, et al. Motor cortex reorganization and repetitive transcranial magnetic stimulation for pain—A methodological study. Neuromodulation,2016,19(7): 669–678. DOI: 10.1111/ner.12444
    [25]
    GATZINSKY K, BERGH C, LILJEGREN A, et al. Repetitive transcranial magnetic stimulation of the primary motor cortex in management of chronic neuropathic pain: A systematic review. Scand J Pain,2020,7;21(1): 8–21. DOI: 10.1515/sjpain-2020-0054
    [26]
    GEOFFREY G, SONYA W, ASHLEYC, et al. Significant reduction in phantom limb pain after low-frequency repetitive transcranial magnetic stimulation to the primary sensory cortex. Mil Med,2015,180(1): 126–128. DOI: 10.7205/MILMED-D-14-00236
    [27]
    DI ROLLO D, PALLANTI S, LAZZARO V. Phantom limb pain: Low frequency repetitive transcranial magnetic stimulation in unaffected hemisphere. Case Rep Med, 2011, 2011: 130751[2020-09-08]. https://doi.org/10.1155/2011/130751.
    [28]
    CHAN B L, WITT R, CHARROW A P, et al. Mirror therapy for phantom limb pain. N Engl J Med,2007,357(21): 2206–2207. DOI: 10.1056/NEJMc071927
    [29]
    FINN S B, PERRY B N, CLASING J E, et al. A randomized, controlled trial of mirror therapy for upper extremity phantom limb pain in male amputees. Front Neurol, 2017, 8: 267[2020-09-08]. https://doi.org/10.3389/fneur.2017.00267.
    [30]
    ROTHGANGEL A, BRAUN S, WINKENS B, et al. Traditional and augmented reality mirror therapy for patients with chronic phantom limb pain (PACT study): Results of a three-group, multicentre single-blind randomized controlled trial. Clin Rehabil,2018,32(12): 1591–1608. DOI: 10.1177/0269215518785948
