Three-Dimensional Nonlinear Finite Element Modeling and Analysis of Concomitant Atlanto-Occipital Fusion and Atlantoaxial Joint Dislocation

XU Chong-xi; TANG Bin; ZENG Xi-hang; HUANG Si-qing; MA Jun-peng

doi:10.12182/20220160203

Volume 53 Issue 1

Jan. 2022

Turn off MathJax

Article Contents

Abstract

References

JOURNAL OF SICHUAN UNIVERSITY (MEDICAL SCIENCES) > 2022 > 53(1): 121-126. > DOI: 10.12182/20220160203

XU Chong-xi, TANG Bin, ZENG Xi-hang, et al. Three-Dimensional Nonlinear Finite Element Modeling and Analysis of Concomitant Atlanto-Occipital Fusion and Atlantoaxial Joint Dislocation[J]. Journal of Sichuan University (Medical Sciences), 2022, 53(1): 121-126. DOI: 10.12182/20220160203

Citation:

PDF (942 KB)

Three-Dimensional Nonlinear Finite Element Modeling and Analysis of Concomitant Atlanto-Occipital Fusion and Atlantoaxial Joint Dislocation

1.
Department of Neurosurgery, West China Hospital, Sichuan University, Chengdu 610041, China
2.
College of Physics, Sichuan University, Chengdu 610065, China

More Information

Corresponding author:
MA Jun-peng, E-mail: majunpenglj@163.com
Received Date: July 04, 2021
Revised Date: December 06, 2021
Available Online: January 23, 2022
Published Date: January 19, 2022

Abstract

Abstract

Objective To establish, with finite element technology, a three-dimensional nonlinear finite element model of the normal occipital bone, atlas and axis and a three-dimensional nonlinear finite element model of concomitant atlanto-occipital fusion and atlantoaxial dislocation, providing a biomechanical method for clinical research on the upper cervical spine.
Methods Finite element analysis was conducted with the CT data of a 27-year-old male volunteer, and a three-dimensional nonlinear finite element model, i.e., the normal model, of the normal occipital bone, atlas and axis was established accordingly. Finite element analysis was conducted with the CT data of a 35-year-old male patient with concomitant atlanto-occipital fusion and atlantoaxial dislocation. Then, the ideal state of a simple ligament rupture under high load was generated by computer simulation, and a three-dimensional nonlinear finite element model of concomitant atlanto-occipital fusion and atlantoaxial dislocation was established, i.e., the atlanto-occipital fusion with atlantoaxial dislocation model. For both models, a vertical upward torque of 1.5 N·m was applied on the upper surface of the occipital bone. Through comparative analysis of the two models under stress, the data of the range of motion (ROM) for flexion, extension, lateral bending, and rotation were examined. In addition, stress and deformation analysis with 1.5 N·m torque load was conducted to validate the effectiveness of the two three-dimensional nonlinear finite element models established in the study.
Results When the normal model established in the study was under 1.5 N·m torque load, it exhibited a maximum ROM for each unit of flexion, extension, and the ROM approximated the experimental measurement results of human mechanics, confirming the validity of the simulation. The stress and deformation results of the model were consistent with the basic principles of mechanics. The moment-angular displacement of the model showed obvious nonlinear characteristics. Compared with the normal model, the atlanto-occipital fusion with atlantoaxial dislocation model showed reduced ROM of the atlanto-occipital joint under a torque of 1.5 N·m, while the ROM of the C1-C2 joint for the four conditions of flexion, posterior extention, lateral bending, and rotation under load, with the exception of rotating motion, was greatly increased compared with that of the normal model, which was in line with the actual clinical performance of the patient.
Conclusion The atlanto-occipital fusion with atlantoaxial dislocation model and the three-dimensional nonlinear finite element model of the normal occipital bone, atlas and axis were successfully established by finite element technology. The models had valid simulation and reliable kinematic characteristics, and could be used as a reliable tool to simulate clinical diseases.
- Atlanto-occipital fusion,
- Atlantoaxial dislocation,
- Atlanto-occipital deformity,
- Finite element model

FullText(HTML)

References (20)

References

[1]	周定标, 张远征, 余新光, 等. 自发性寰枢椎脱位(附155例报告). 中华神经外科杂志,2000,16(5): 270–273. DOI: 10.3760/j.issn:1001-2346.2000.05.002
[2]	余新光, 尹一恒, 周定标, 等. 颅颈交界畸形寰枢侧方关节与寰枢稳定性的关系. 中华神经外科杂志,2011,27(10): 1029–1033. DOI: 10.3760/cma.j.issn.1001-2346.2011.10.018
[3]	段光明. 枕寰枢关节非线性有限元模型构建及有效性验证. 中华神经外科疾病研究杂志,2014,13(1): 73–74.
[4]	郭群峰, 陈方经, 倪斌, 等. 带有颅底的全颈椎三维有限元模型的建立及分析. 中国脊柱脊髓杂志,2014,24(6): 550–554. DOI: 10.3969/j.issn.1004-406X.2014.06.11
[5]	陈赞, 吴浩, 王兴文, 等. 寰椎侧块螺钉治疗寰枕融合合并寰枢椎脱位的临床报告. 脊柱外科杂志,2011,9(3): 162–164. DOI: 10.3969/j.issn.1672-2957.2011.03.009
[6]	邓达人, 孟春玲, 陈宏健, 等. 基于流体动力学网格技术建立寰枕融合的全颈椎有限元模型//第十三届中国CAE工程分析技术年会论文集. 成都: 中国力学学会产学研工作委员会、中国机械工程学会机械工业自动化分会, 等, 2017: 63-65.
[7]	陈金水, 倪斌, 陈博, 等. 寰枢椎脱位三维非线性有限元模型的建立和分析. 中国脊柱脊髓杂志,2010,20(9): 749–753. DOI: 10.3969/j.issn.1004-406X.2010.09.13
[8]	刘海波. 上颈椎（C0-C3）有限元模型的建立及损伤内固定的分析. 太原: 太原理工大学, 2015.
[9]	ZHANG Y K, LI C, LI L, et al. Design a novel integrated screw for minimally invasive atlantoaxial anterior transarticular screw fixation: a finite element analysis. J Orthop Surg Res, 2020, 15(1): 11[2021-06-21]. https://doi.org/ 10.1186/s13018-020-01764-w.
[10]	尹一恒, 余新光, 王鹏, 等. 寰枕融合下的颅颈交界区有限元生物力学分析. 中华外科杂志,2015,53(3): 211–214. DOI: 10.3760/cma.j.issn.0529-5815.2015.03.015
[11]	KUMARESAN S, YOGANANDAN N, PINTAR F A, et al. Finite element modeling approaches of human cervical spine facet joint capsule. J Biomechanics,1998,31(4): 371–376. DOI: 10.1016/S0021-9290(98)00008-6
[12]	BREKELMANS W A, POORT H W, SLOOFF T J. A new method to analyse the mechanical behaviour of skeletal parts. Acta Orthop Scand,1972,43(5): 301–317. DOI: 10.3109/17453677208998949
[13]	SAITO T, YAMAMURO T, SHIKATA J, et al. Analysis and prevention of spinal column deformity following cervical laminectomy. I Pathogenetic Analysis of postlaminectomy deformities. Spine,1991,16(5): 494–502. DOI: 10.1097/00007632-199105000-00002
[14]	YOGANANDAN N, KUMARESAN S, VOO L, et al. Finite element applications in human cervical spine modeling. Spine (Phila Pa 1976),1996,21: 1824–1834. DOI: 10.1097/00007632-199608010-00022
[15]	KOPPERDAHL D L, MORGAN E F, KEAVENY T M, et al. Quantitative computed tomography estimates of the mechanical properties of human vertebral trabecular bone. J Orthop Res,2002,20(4): 801–805. DOI: 10.1016/S0736-0266(01)00185-1
[16]	RHO J Y, HOBATHO M C, ASHMAN R B. Relations of mechanical properties to density and CT numbers in human bone. Med Eng Phys,1995,17(5): 347–355. DOI: 10.1016/1350-4533(95)97314-F
[17]	PANJABI M, DVORAK J, CRISCO J J, et al. Flexion, extension, andlateral bending of the upper cervical spine in response toalarligament transections. J Spinal Disord,1991,4(2): 157–167. DOI: 10.1097/00002517-199106000-00005
[18]	BROlIN K, HALLDIN P. Development of a finite element model of the upper cervical spine and a parameter study of ligament characteristics. Spine,2004,29(4): 376–385. DOI: 10.1097/01.BRS.0000090820.99182.2D
[19]	夏虹, 赵卫东, 黄文华, 等. 寰椎不同类型骨折对上颈椎稳定性影响的生物力学研究. 中国临床解剖学杂志,2003,21(5). DOI: 10.13418/j.issn.1001-165x.2003.05.033
[20]	KALLEMEYN N, GANDHIET A, KODE S, et al. Validation of a C2-C7 cervical spine finite element model using specimen-specific flexibility data. Med Eng Phys,2010,32(5): 482–489. DOI: 10.1016/j.medengphy.2010.03.001
